Football
Scoreboards
|
Description
|
Board |
Digits |
Score |
More Info |
|
GM-FB-00
Excellent standard board. Good value. |
Click On Scoreboards For More
Information |
Football Scoreboards.
Includes horn. Has
17" tall LED displays on the top and bottom. Score up to 99.
49" high x 121" wide x 2" deep. Approximate weight is 100
lbs. Shipping weight is approximately 130 lbs. Uses less than 2 amps @ 120 volts AC. |
10'1"
Wide |
17" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info
|
|
GM-FB-08
Lower cost. Good for smaller
fields. |

Click On Scoreboards For More
Information |
Football Scoreboards.
Includes horn. Has
9" tall LED displays on the top and bottom. Score up to 99.
36" high x 72" wide x 2" deep. Approximate weight is 65
lbs. Shipping weight is approximately 100 lbs. Uses less than 2 amps @ 120 volts AC. |
6'0"
Wide |
9" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info
|
|
GM-FB-00TOL
Includes TOL displays and
Possession indicators. |

Click On Scoreboards For More
Information |
Football Scoreboards.
Includes horn. Has
17" tall LED displays on the top and bottom, 9" tall digits for time outs left
displays. Score up to 99.
49" high x 121" wide x 2" deep. Approximate weight is 90
lbs. Shipping weight is approximately 180 lbs. Uses less than 2 amps @ 120 volts AC. |
10'1"
Wide |
17" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info
|
|
9" Tall |
|
GM-FB-01
Includes Down, To Go, and Ball On
displays. |

Click On Scoreboards For More
Information
|
Football Scoreboards.
Includes horn. Has
17" tall LED displays on the top and bottom. Score up to 99. Game
time / day time. 60" high x 169" wide x 2" deep.
Approximate weight is 150 lbs. Shipping weight is approximately 270 lbs. Uses less than 4 amps @ 120 volts AC. |
14'1"
Wide |
17" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info
|
|
GM-FB-012
Similar to FB-01 plus 1st Down,
Rush Yards, and Pass Yards. |

Click On Scoreboards For More
Information |
Football Scoreboards.
Includes horn. Has
17" tall LED displays on the top and middle, 9" tall displays on the bottom. Score up to 99. Game
time / day time. 82" high x 169" wide x 2" deep.
Approximate weight is 200 lbs. Shipping weight is approximately 350 lbs. Uses 6 amps @ 120 volts AC. |
14'1"
Wide |
17" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info |
|
9" Tall |
|
GM-FB-01+MX01
FB-01 with MX-01 message board. Click On Scoreboards For More
Information |

Click On Scoreboards For More
Information |
Football Scoreboard with
MB-MX-01 matrix message board.
Includes horn. Has
17" tall LED displays on the top and bottom. Score up to 99. Game
time / day time. 72" high x 169" wide x 2" deep.
Approximate weight is 210 lbs. Shipping weight is approximately 330 lbs. Uses less than 7 amps @ 120 volts AC. |
14'1"
Wide |
17" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info |
|
GM-FB-02
Includes
Possession indicators, TOL, Down, To Go, and Ball On
displays. |

|
Football Scoreboards.
Includes horn. Has
17" tall LED displays on the top and bottom. Score up to 99. 9"
tall time outs left indicators. Possession indicators. Game time /
day time. 60" high x 169" wide x 2" deep. Approximate
weight is 200 lbs. Shipping weight is approximately 230 lbs. Uses less than 4 amps @ 120 volts AC. |
14'1"
Wide |
17" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info
|
|
9" Tall |
|
GM-FB-04
Larger version of FB-02 with 24
inch and 17 inch tall displays. |

Click On Scoreboards For More
Information |
Football Scoreboards.
Includes horn. Has
24" tall LED displays on the top and bottom. Score up to 99. 17"
tall time outs left indicators. Possession indicators. Game time /
day time. 67" high x 288" wide x 2" deep. Approximate
weight is 300 lbs. Shipping weight is approximately 500 lbs. Uses 6 amps at 120 volts AC. |
24'0"
Wide |
24" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info
|
|
17" Tall |
|
GM-FB-041
Similar to FB-04 but includes
tenths of seconds display on game clock. |

Click On Scoreboards For More
Information
|
Football Scoreboards.
Includes horn. Has
24" tall LED displays on the top and bottom. Score up to 99. 17"
tall time outs left indicators. Possession indicators. Game time
with tenths of seconds / day time. 67" high x 288" wide x 2"
deep. Approximate weight is 300 lbs. Shipping weight is
approximately 500 lbs. Uses 6 amps at 120 volts AC. |
24'0"
Wide |
24" Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info
|
|
17" Tall |
|
GM-FB-05
Larger board with 24
inch tall displays. Displays all statistics except ones of FB-012. |

Click On Scoreboards For More
Information |
Football Scoreboards.
Includes horn. Has
30" tall LED displays on the top and bottom. Score up to 99. 17"
tall time outs left indicators. Possession indicators. Game time /
day time. 96" high x 336" wide x 2" deep. Approximate
weight is 540 lbs. Shipping weight is approximately 760 lbs. Uses 6 amps at 120 volts AC. |
28'0"
Wide |
24"
Tall |
Up To 99 |
Options
Print Specs
Brochures
Request More Info |
|
17" Tall |
|
GM-HC-01
Wireless control means just plug
these in and play. Strong and lightweight. |

Click On Scoreboards For More
Information
|
Huddle Clocks.
Includes horn. LED digits can be 17", 24" or 30".
17" Digit display: 29" H x 25" W x 2" D. Weight: 30 Lbs.
24" Digit display: 34" H x 43" W x 2" D. Weight: 40 Lbs.
30" Digit display: 43" H x 44" W x 2" D. Weight: 40 Lbs.
Uses less than 1 amp @ 120 V AC. |
Width
Depends on Display Size
|
17" Tall |
N/A |
Options
Print Specs
Brochures
Request More Info
|
24"
Tall
30"
Tall
|
|
GM-HC-02
Legs with wheels makes these easy
to transport to and from field. Rugged for years of use. |

Click On Scoreboards For More
Information
|
Huddle Clocks.
Includes horn. LED digits can be 17", 24" or 30".
17" Digit display: 29" H x 25" W x 2" D. Weight: 50 Lbs.
24" Digit display: 34" H x 43" W x 2" D. Weight: 65 Lbs.
30" Digit display: 43" H x 44" W x 2" D. Weight: 65 Lbs.
Product stands between 60" - 66" from ground depending on digit size.
Uses less than 2 amps @ 120 V AC. |
Width Depends on Display Size |
17" Tall |
N/A |
Options
Print Specs
Brochures
Request More Info
|
24"
Tall
30"
Tall
|
